Auto Hydraulic Force Stamping machine

Max Stamp size: 550X450mm
Stamping precision: ±0.1mm
Pressure power: 10T
Overlay the stamped logo

Price Interview

Price Interview

Auto Hydraulic Force Stamping machine

Interview

Select the number of specifications

Please check the product information you want!

Product Detail Inquiry

Online Video:


Max Stamp size: 550X450mm

Stamping precision: ±0.1mm

Pressure power: 10T

Overlay the stamped logo


Auto Falt Hydraulic Power Hot Stamp Machines Ky-800S are used for applying large labels requiring extensive pressure.

These machines typically range from 7 to 15 tons of force and have longer stroke lengths.

They are often used for decorating large items such as Luxury package, buckets, pails, cases, and garbage cans.

The machines typically have a heavy-duty machine frame, a hydraulic power unit with a 5HP TEFC 230/460 VAC 3 phase electric motor,

and a high performance oil pump.

The Large Pressure Hydraulic Hot Stamping Machines (H-TCH-500) have a power rate of 220V 50HZ, a stamping area of 300 x 400mm, 400x400mm, or 450x550mm, and a stamping pressure of 20 tons.


ModelKy-500SKy-700SKy-800S
Max paper size500X500mm700X550mm800X550mm
Min paper size100X100mm100X100mm100X100mm
Max stamp size150X150mm300X200mm550X450mm
Min stamp size10X10mm10X10mm10X10mm
Voltage380V220V380V
Power2.5KW3.5KW9.25KW
Max pressure1.5T2.5T10T
Stamping Prescision±0.2mm±0.1mm±0.1mm
Stamping Speed1200-1500Pcs/H1200-1500Pcs/H1200-1500Pcs/H
Machine dimension1700X825X1664mm2000X1100X1772mm2100X1400X2100mm
Machine Weight620Kg810Kg1600Kg
