The Magnet inserts machine makes boxes with sophisticated magnetic closures, our magnet pasting machine automatically mills the blind holes for the magnets, apply the glue and insert the magnets or steel studs.
Benefits
With magnetic closures you get the reassurance of a soft, but clearly audible, clunk as the magnets connect.
It’s especially impressive with high-end, reclosable luxury packaging.
Fewer process steps – no separate hole punching, no extra label application
Lower material costs with steel studs Perfectly laminated layers over magnets/studs, so no blemishes on box cover
Features
Gluing station with nozzle system Separation from magnet hopper Feeder system for up to 4 magnets or steel studs Simple adjustment for format changes Milling station
Auto magnets insert machine
Specfication
| Model | Ky-360A |
| Max size of board | 500*900mm |
| Min size of board | 100*60mm |
| Board thickness | 1-3mm |
| Max distance of two milling holes | 420mm |
| Min distance of two milling holes | 70mm |
| Magnet diameter | Φ8mm-Φ16mm |
| Max distance of two magnet insert | 420mm |
| Min distance of two magnet insert | 56mm |
| Work speed | 20-35pcs/min |
| Glue tank capacity | 2 L |
| Air pressure | 0.6MPa |
| Power | 3.5Kw |
| Machine size | 3800*1940*1650mm |
| Machine weight | 1200Kg |
